PD1320Wi
19 Sep

PD1320Wi

PD1320Wi

Share your ideas wherever you go with Acer Portable LED Projectors.

Discuss concepts, show videos on big screens and motivate others while you’re on the road — without needing a computer. With models as slim as 1″ (24.5 mm), the world of self-expression now fits in your pocket.

Specifications:


Native Resolution1280 x 800
Maximum Resolution1920 x 1200
Standard Mode Brightness3000 lm
Native Aspect Ratio16:10
Compatible Aspect Ratio16:9
4:3
Contrast Ratio1,000,000:1
Vertical Keystone Correction-40°/+40°
Maximum Vertical Sync120 Hz
Maximum Horizontal Sync100 kHz
Minimum Vertical Sync24 Hz
Colour Support16.7 Billion Colours

Projection Lens

Throw Ratio
1.27 (73.4″@2m)
Lens TypeManual Focus
Maximum Lens ApertureF/1.7
Maximum Focal Length12.60 mm
Minimum Diagonal Image Size75 cm (29″)
Maximum Diagonal Image Size7.62 m (300″)
Minimum Projection Distance0.8 m
Maximum Projection Distance8.20 m
Optical Zoom1 x

Lamp

Lamp TypeLED
Number of Lamps1
Normal Mode Lamp Life20,000 Hours
Economy Mode Lamp Life30,000 Hours

Interfaces/ Ports

HDMIYes
Total Number of HDMI Ports1
Number of Audio Inputs1
Number of Audio Outputs1
Audio Line InYes
Audio Line OutYes
USBYes
Number of USB Ports1
Composite VideoYes
Number of VGA Inputs1
VGA InYes

Technical Information

Projection SystemDLP
Projection MethodCeiling
Front
Rear
Rear Ceiling
Video CompatibilityEDTV
HDTV
NTSC
PAL
SDTV
SECAM
Computer CompatibilityMac PC
Windows PC
Wireless CapabilityYes
(By optional WirelessProjection-Kit: UWA3 and UWA5)

Audio

Number of Speakers1
Speaker Output Power3 W
Speaker Output ModeMono

Multimedia Features

Multimedia PlaybackAdobe PDF Viewer
Audio Playback
Microsoft Excel
Microsoft PowerPoint
Microsoft Word
Photo Slide Show
Video Playback

Supported Multimedia Formats

Audio FormatsAAC
MP3
PCM
WAV
WMA

Power Description

Power Supply100 V AC~240 V AC
Input Voltage120 V AC
230 V AC
Operating Power Consumption177 W
Operating Power Consumption
(Eco Mode)
74 W

Physical Characteristics

Temperature0°C to 40°C
Fan Noise26 dB Approximate Economy Mode
32 dB Approximate Standard Mode
Humidity80% Maximum Relative Humidity
Weight (Approximate)2.20 kg
Form FactorCeiling Mountable

Miscellaneous

Package ContentsPD1320W DLP Projector
AC Power Cord
Remote Control
Battery for Remote Control
Lens Cap
Carrying Case
User’s Guide (CD-ROM)
Quick Start Guide

Warranty

Warranty2 Years (Upgradeable)

SRP: RM 2,999

PD1520i
18 Sep

PD1520i

PD1520i

Share your ideas wherever you go with Acer Portable LED Projectors.

Discuss concepts, show videos on big screens and motivate others while you’re on the road — without needing a computer. With models as slim as 1″ (24.5 mm), the world of self-expression now fits in your pocket.

Specifications:


Native Resolution1920 x 1080
Maximum Resolution3840 x 2160
Standard Mode Brightness3000 lm
Native Aspect Ratio16:9
Compatible Aspect Ratio4:3
Contrast Ratio1,000,000:1
Vertical Keystone Correction-40°/+40°
Maximum Vertical Sync120 Hz
Maximum Horizontal Sync100 kHz
Minimum Vertical Sync24 Hz
Colour Support10.7 Billion Colours

Projection Lens

Throw Ratio
1.2 (75.1″@2m)
Lens TypeManual Focus
Maximum Lens ApertureF/1.7
Maximum Focal Length12.60 mm
Minimum Diagonal Image Size76 cm (30″)
Maximum Diagonal Image Size7.62 m (300″)
Minimum Projection Distance0.8 m
Maximum Projection Distance8.0 m
Optical Zoom1 x

Lamp

Lamp TypeRGB LED
Number of Lamps1
Normal Mode Lamp Life20,000 Hours
Economy Mode Lamp Life30,000 Hours

Interfaces/ Ports

HDMIYes
Total Number of HDMI Ports1
Number of Audio Inputs1
Number of Audio Outputs1
Audio Line InYes
Audio Line OutYes
USBYes
Number of USB Ports1
Composite VideoYes
Number of VGA Inputs1
VGA InYes

Technical Information

Projection SystemDLP
Projection MethodCeiling
Front
Rear
Rear Ceiling
Video CompatibilityEDTV
HDTV
NTSC
PAL
SDTV
SECAM
Computer CompatibilityMac PC
Windows PC
Wireless CapabilityYes
(By optional WirelessProjection-Kit: UWA3 and UWA5)

Audio

Number of Speakers1
Speaker Output Power3 W
Speaker Output ModeMono

Multimedia Features

Multimedia PlaybackAdobe PDF Viewer
Audio Playback
Microsoft Excel
Microsoft PowerPoint
Microsoft Word
Photo Slide Show
Video Playback

Supported Multimedia Formats

Audio FormatsAAC
MP3
PCM
WAV
WMA

Power Description

Power Supply100 V AC~240 V AC
Input Voltage120 V AC
230 V AC
Operating Power Consumption177 W
Operating Power Consumption
(Eco Mode)
74 W

Physical Characteristics

Temperature0°C to 40°C
Fan Noise26 dB Approximate Economy Mode
32 dB Approximate Standard Mode
Humidity80% Maximum Relative Humidity
Weight (Approximate)2.20 kg
Form FactorCeiling Mountable

Miscellaneous

Package ContentsPD1520 DLP Projector
AC Power Cord
Remote Control
Battery for Remote Control
Lens Cap
Carrying Case
User’s Guide (CD-ROM)
Quick Start Guide

Warranty

Warranty2 Years (Upgradeable)

SRP: RM 3,699

Imago Smart Interactive Flat Panel
10 Jul

Imago Smart Interactive Flat Panel

The Smartest Way to Teach, Learn, Meet & Collaborate!

  • Interactive Teaching & Learning with effective & collaborative classroom management
  • Powerful video conference collaboration, get the most out of your teaching & learning
  • Electromagnetic / IR & Capacitive Dual Touch, Original Handwriting
  • Android Operation System with Smooth Operation

Acer TravelMate X3310
8 May

Acer TravelMate X3310

TravelMate X3310-M-5407TravelMate X3310-M-5407TravelMate X3310-M-5407TravelMate X3310-M-5407TravelMate X3310-M-5407TravelMate X3310-M-5407

Optimized for productivity, security, and reliability the TravelMate X3 is a serious business-class laptop for true professionals.

*Limited stock – While stock last*

Check out the Specifications we have below:

TravelMate X3310-M-5407

Operating System Windows® 10 Professional 64 bit with Acer Recovery Management
Processor Intel® Core™ i5-8250U (1.6GHz-3.4GHz Turbo/6MB Cache/4 Cores/8 Threads)
Memory 8GB DDR4 Memory, up to 32GB
Card Reader SD™ Card Reader
Storage 256SSD M.2 SATA Solid State Drive
Screen 13.3″ FHD 1920×1080 resolution, IPS (In Plane Switching), Acer ComfyView™
Camera 720p HD HDR (High Dynamic Range) Camera, 88 degrees Wide Angle lens, excellent for Video Conferencing
Audio Stereo speakers, Acer TrueHarmony technology, Skype for Business Certified
Graphics Intel® UHD Graphics 620. VGA & HDMI with HDCP ports
Connectivity 802.11ac, Acer Nplify™, 2×2 MIMO WiFi & Bluetooth 4.2
Ports & Connectors One USB Type C™ (with USB 3.1 Gen 1 5Gbps, DisplayPort of USB-C, USB Charging 5V/3A, DC-in 20V/45W), Three USB 3.0 Ports (with power-off charging)
Input Devices TouchPad
Battery 3 Cell Li-ion Battery
  Up to 15 hours
Adapter 3-pin 65W AC adapter
Dimensions (W x D x H) 328 (W) x 238 (D) x 19.9 (H) mm,
Weight (Approximate) 1.6kg
Package Contents TravelMate X3310-M-5407,  Lithium-Ion Battery & AC Adapter & Acer Laptop Backpack
Security Biometric Fingerprint Solution, Trusted Platform Module (TPM), Kensington lock slots. BIOS, User, Supervisor HDD password protection

System Recovery

Acer Recovery Management with One-Button Recovery – Easy OS recovery solution
System Compliance & Certifications Energy Star®
Warranty Three years Parts & Labors, Carry-in warranty with one year International Traveler Warranty (ITW). Free upgrade to Three years Parts, Labor & On-site Warranty with One Year ITW worth rm98
Suggested Retail Price  RM 3,799



Acer TravelMate P214
7 May

Acer TravelMate P214

A Portable Office

At just 1.6kg1 and less than 20mm1 thin, this device easily fits into a briefcase or travel bag. Enjoy stunning visuals with the up to 15” IPS display, with narrow bezels1for a high screen-to-body ratio. Work comfortably in any situation with the LED backlit keyboard, precision touchpad and 180° hinge.

NEW!!!

TravelMate P214-51-398Q

Specification:

Operating System Windows® 10 Professional
Processor Intel® Core i3-8130U (2.20GHz, Dual-core)
Memory 4GB DDR4 Memory
Card Reader SD™ Card Reader
Optical Drive No
Storage 1 TB 7.2Krpm
Screen 14” HD 1366 x 768, ComfyView, LED Backlight technology
Built in Devices 2 Stereo speakers (Front Facing), Microphone
Graphics Intel® HD Graphics 620, LCD,
Connectivity IEEE 802.11a/b/g/n/ac, Gigabit Ethernet, Bluetooth 4.2
Ports & Connectors One USB Type C™ (with USB 3.1 Gen 1 5Gbps, DisplayPort of USB-C, USB Charging 5V/3A, DC-in 20V/60W) & Two USB 2.0 ports, One USB 3.1 Gen 1 ( Power-off USB Charging)
Input Devices Precision TouchPad
Battery 3 Cell Li-ion Battery
Up to 14.5 hours
Adapter 3-pin 45W AC adapter
Dimensions (W x D x H) 349 (W) x 250 (D) x 19.9 (H) mm
Weight (Approximate) 1.67kg
Package Contents TravelMate P214-51-398Q, Lithium-Ion Battery & AC Adapter & Acer Laptop Backpack
Security Trusted Platform Module (TPM), Kensington lock slots. BIOS, User, Supervisor HDD password protection
Bundled Solution 1.     Acer Recovery Management with One-Button Recovery – Easy OS recovery  solution

2.     30 days Anti Virus

3.     Acer ProShield Security Manager :-

a.      Facial Recognition Login

b.     Data Protection: File Encryption & Decryption, Personal Secure Drive

c.      Data Removal: File Shredder

System Compliance

& Certifications

Energy Star®
Warranty Three years Parts & Labor, Onsite Warranty  with One year International Traveler Warranty (ITW)
Suggested Retail Price      Rm 2,599

TravelMate P214-51-55V4

Specification:

Operating System Windows® 10 Professional
Processor Intel® Core i5-8250U (1.6GHz-3.4GHz Turbo/6MB Cache/4 Cores/8 Threads)
Memory 4GB DDR4 Memory, up to 20GB
Card Reader SD™ Card Reader
Optical Drive No
Storage 1 TB 7.2Krpm
Screen 14” HD 1366 x 768, ComfyView, LED Backlight technology
Built in Devices 2 Stereo speakers (Front Facing), Microphone
Graphics Intel® HD Graphics 620, LCD,
Connectivity IEEE 802.11a/b/g/n/ac, Gigabit Ethernet, Bluetooth 4.2
Ports & Connectors One USB Type C™ (with USB 3.1 Gen 1 5Gbps, DisplayPort of USB-C, USB Charging 5V/3A, DC-in 20V/60W) & Two USB 2.0 ports, One USB 3.1 Gen 1 ( Power-off USB Charging)
Input Devices Precision TouchPad
Battery 3 Cell Li-ion Battery
Up to 14.5 hours
Adapter 3-pin 45W AC adapter
Dimensions (W x D x H) 349 (W) x 250 (D) x 19.9 (H) mm
Weight (Approximate) 1.67kg
Package Contents TravelMate P214-51-55V4, Lithium-Ion Battery & AC Adapter & Acer Laptop Backpack
Security Trusted Platform Module (TPM), Kensington lock slots. BIOS, User, Supervisor HDD password protection
Bundled Solution 1.     Acer Recovery Management with One-Button Recovery – Easy OS recovery  solution

2.     30 days Anti Virus

3.     Acer ProShield Security Manager

a.      Facial Recognition Login

b.     Data Protection: File Encryption & Decryption, Personal Secure Drive

c.      Data Removal: File Shredder

System Compliance

& Certifications

Energy Star®
Warranty Three years Parts & Labor, Onsite Warranty  with One year International Traveler Warranty (ITW)
Suggested Retail Price      Rm 2,899

TravelMate P214-51-50D8

Specification:

Operating System Windows® 10 Professional 64 bit with Acer Recovery Management
Processor Intel® Core i5-8250U (1.6GHz-3.4GHz Turbo/6MB Cache/4 Cores/8 Threads)
Memory 4GB DDR4 Memory, up to 20GB
Card Reader SD™ Card Reader
Optical Drive Yes
Storage 1 TB 7.2Krpm
Screen 14” HD 1366 x 768, ComfyView, LED Backlight technology
Built in Devices 2 Stereo speakers (Front Facing), Microphone
Graphics Intel® HD Graphics 620, VGA & HDMI 2.0 with HDCP support
Connectivity IEEE 802.11a/b/g/n/ac, Gigabit Ethernet, Bluetooth 4.2
Ports & Connectors One USB Type C™ (with USB 3.1 Gen 1 5Gbps, DisplayPort of USB-C, USB Charging 5V/3A, DC-in 20V/60W) & Two USB 2.0 ports, One USB 3.1 Gen 1 ( Power-off USB Charging)
Input Devices Precision TouchPad
Battery 3 Cell Li-ion Battery
Up to 14.5 hours
Adapter 3-pin 45W AC adapter
Dimensions (W x D x H) 349 (W) x 250 (D) x 19.9 (H) mm
Weight (Approximate) 1.79kg
Package Contents TravelMate P214-51-50D8, Lithium-Ion Battery & AC Adapter & Acer Laptop Backpack
Security Trusted Platform Module (TPM), Kensington lock slots. BIOS, User, Supervisor HDD password protection
1.     Bundled Solution 1.     Acer Recovery Management with One-Button Recovery – Easy OS recovery  solution

2.     30 days Anti Virus

3.     Acer ProShield Security Manager

a.      Facial Recognition Login

b.     Data Protection: File Encryption & Decryption, Personal Secure Drive

c.      Data Removal: File Shredder

System Compliance

& Certifications

Energy Star®
Warranty Three years Parts & Labor, Onsite Warranty  with One year International Traveler Warranty (ITW)
Suggested Retail Price      Rm 2,999

TravelMate P214-51-510Z

Specification

Operating System Windows® 10 Professional 64 bit with Acer Recovery Management
Processor Intel® Core i5-8250U (1.6GHz-3.4GHz Turbo/6MB Cache/4 Cores/8 Threads)
Memory 4GB DDR4 Memory, up to 20GB
Card Reader SD™ Card Reader
Optical Drive Yes
Storage 256GB SSD M.2 PCIE NVME
Screen 14” HD 1366 x 768, ComfyView, LED Backlight technology
Built in Devices 2 Stereo speakers (Front Facing), Microphone
Graphics Intel® HD Graphics 620, VGA & HDMI 2.0 with HDCP support
Connectivity IEEE 802.11a/b/g/n/ac, Gigabit Ethernet, Bluetooth 4.2
Ports & Connectors One USB Type C™ (with USB 3.1 Gen 1 5Gbps, DisplayPort of USB-C, USB Charging 5V/3A, DC-in 20V/60W) & Two USB 2.0 ports, One USB 3.1 Gen 1 ( Power-off USB Charging)
Input Devices Precision TouchPad
Battery 3 Cell Li-ion Battery
Up to 14.5 hours
Adapter 3-pin 45W AC adapter
Dimensions (W x D x H) 349 (W) x 250 (D) x 19.9 (H) mm
Weight (Approximate) 1.67kg
Package Contents TravelMate P214-51-510Z, Lithium-Ion Battery & AC Adapter & Acer Laptop Backpack
Security Trusted Platform Module (TPM), Kensington lock slots. BIOS, User, Supervisor HDD password protection
1.     Bundled Solution 1.     Acer Recovery Management with One-Button Recovery – Easy OS recovery  solution

2.     30 days Anti Virus

3.     Acer ProShield Security Manager

a.      Facial Recognition Login

b.     Data Protection: File Encryption & Decryption, Personal Secure Drive

c.      Data Removal: File Shredder

System Compliance

& Certifications

Energy Star®
Warranty Three years Parts & Labor, Onsite Warranty  with One year International Traveler Warranty (ITW)
Suggested Retail Price      Rm 3,099
Acer Chromebook 11
8 Apr

Acer Chromebook 11

Acer Chromebook 11 C732 C732T gallery 01Acer Chromebook 11 C732 C732T gallery 02Acer Chromebook 11 C732 C732T gallery 03Acer Chromebook 11 C732 C732T gallery 04Acer Chromebook 11 C732 C732T gallery 05Acer Chromebook 11 C732 C732T gallery 06Acer Chromebook 11 C732 C732T gallery 07Acer Chromebook 11 C732 C732T gallery 08

A high performance and ultra-durable laptop that can meet the daily rigors and intense usage by students inside the classroom or outside.

Check out the specifications below:

Chromebook 11 C732 – C0XX

Operating SystemChrome OS
ProcessorCeleron N3450
Memory4GB LPDDR4
Card ReaderMicro SD Card Reader
Storage32GB eMMC
Screen11.6″ HD 1366×768 resolution Acer ComfyView™ with 180 degree hinge
Camera720p HD Camera, excellent for Video Conferencing
AudioHigh Definition Stereo speakers
GraphicsIntel HD Graphics 500
Connectivity802.11ac, 2×2 MIMO WiFi, Bluetooth 4.2
Ports & Connectors“USB Type-C™ port supporting:
• USB 3.1 Gen 1 (up to 5 Gbps)
• DisplayPort over USB-C
• USB charging 5/9/15/20 V; 3 A
• DC-in port 20 V; 45 W
Input DevicesTouchPad
Battery3 Cell Li-ion Battery, Up to 12 hours
AdapterUSB Type-C 45 W Google PD AC Adapter
Dimensions (W x D x H)302 (W) x 209 (D) x 21.3 (H) mm
Weight (Approximate)1.26kg
Package ContentsAcer TravelMate X514-51T,  Lithium-Ion Battery & AC Adapter & Acer Laptop Backpack
SecurityTrusted Platform Module (TPM), Kensington lock slots
System RecoveryAcer Recovery Management with One-Button Recovery – Easy OS recovery solution
System Compliance & CertificationsEnergy Star®
WarrantyOne years Parts & Labor, Carry-in warranty with One year International Traveler Warranty (ITW)
Suggested Retail PriceRM 1,199

Chromebook 11 C733-C8R2

Operating SystemChrome OS
ProcessorCeleron N4100
Memory4GB LPDDR4
Card ReaderMicro SD Card Reader
Storage32GB eMMC
Screen11.6″ HD 1366×768 resolution Acer ComfyView™ with 180 degree hinge
Camera720p HD Camera, excellent for Video Conferencing
AudioHigh Definition Stereo speakers
GraphicsIntel HD Graphics 500
Connectivity802.11ac, 2×2 MIMO WiFi, Bluetooth 4.2
Ports & Connectors“USB Type-C™ port supporting:
• USB 3.1 Gen 1 (up to 5 Gbps)
• DisplayPort over USB-C
• USB charging 5/9/15/20 V; 3 A
• DC-in port 20 V; 45 W
Input DevicesTouchPad
Battery3 Cell Li-ion Battery, Up to 12 hours
AdapterUSB Type-C 45 W Google PD AC Adapter
Dimensions (W x D x H)302 (W) x 209 (D) x 21.3 (H) mm
Weight (Approximate)1.26kg
Package ContentsAcer TravelMate X514-51T,  Lithium-Ion Battery & AC Adapter & Acer Laptop Backpack
SecurityTrusted Platform Module (TPM), Kensington lock slots
System RecoveryAcer Recovery Management with One-Button Recovery – Easy OS recovery solution
System Compliance & CertificationsEnergy Star®
WarrantyOne years Parts & Labor, Carry-in warranty with One year International Traveler Warranty (ITW)
Suggested Retail Price RM 1,299

Altos R380 F4 Server
5 Apr

Altos R380 F4 Server

The Altos R380 F4 is a robust two-socket 2U system that is ideal for almost any application. This dynamic system can function as a computing node for your HPC (High-Performance Computing) environments, or used for virtualization purposes in your cloud infrastructure. Extremely powerful and highly efficient, this system functions as the core for your most demanding data-center needs.

Specification

Form Factor 2U rack optimized, w/ sliding rails
Processor type Up to 2 x Intel® Xeon® Processor Scalable Familiy
Chipset Intel® C624 series chipset
Graphics Integrated 2D video controller

16MB DDR4 video memory

Memory Capacities 8/16GB DIMMs Registered

32/64GB DIMMs Load Reduced

DIMM number 24
Memory Type Registered/Load Reduced DDR4 2666MT/s ECC memory
Max Memory 768 (RDIMM) / 1563GB (LRDIMM) [Processor SKU dependency]
Expansion slots Three riser slots provide:

Riser slot 1:

3-slot riser card: 2 x PCIe 3.0 x16(x8) and 1 x PCIe 3.0 x8(x8)

Riser slot 2:

3-slot riser card: 2 x PCIe 3.0 x16(x8) and 1 x PCIe 3.0 x8(x8)

Riser slot 3:

2-slot riser card: 1 x PCIe 3.0 x8(x8) and 1 x PCIe 3.0 x8(x4) [Optional]

1 x I/O module expansion slot

1 x RAID module expansion slot

Onboard ports Front:

LED indicators: power, HDD activity, LAN, system ID

VGA, 2 x USB 3.0 ports [SKU dependent]

Rear:

2 x 10Gigabit LAN ports (RJ-45) [SKU dependent]

Management port (RJ-45)

Serial port B [optional]

Video port

3 x USB 3.0 ports

Serial Port A (RJ-45)

2 x 2.5″ SSDs (hot-swappable, optional)

Controllers
Controller Type 12Gb/s SAS

Serial ATA

RAID Supported Yes
RAID Levels 0,1,5,10
Network & Communication
Ethernet Technology 10 Gigabit Ethernet
System cooling Six managed, hot-swappable fans keep the system running cool at all times
Power Description
Number of Power Supplies Installed 1
Maximum Power Supply Wattage 1.30 kW
Dimensions 439 (W) x 769 (D) x 89 (H) mm
OS Support Microsoft® Windows Server® 2016 / 2012 R2

Red Hat® Enterprise Linux® 7.3

SUSE® Linux® Enterprise Server 12 SP2

VMware ESXi™ 6.5

Certifications & Standards CC (Class A)

CE (Class A)

BSMI (Class A)

MET

CB

Country of Origin China
Warranty 3/3/3 Next Business Day



SRP RM 15488
Altos T310 F4 Server
5 Apr

Altos T310 F4 Server

Model Name: Acer Altos T310 F4

Specification

Form Factor Extended ATX (12″ x 13″)
Processor type Intel® Xeon® E3-1200 v5/v6 product family

Intel® 7th/6th Gen. Core™ i3 series

Intel® 7th/6th Gen. Celeron® and Intel® Pentium®

Number of processors One
Chipset Intel® C232 chipset
Graphics Embedded controller – 32MB dedicated memory
Memory1 4 x DIMM slots (2 DIMM per channel)

1. Based on Intel CPU spec., Core i7/i5/i3 cannot support ECC UDIMM

Max memory Up to 64GB, using unbuffered DDR4 ECC/non ECC DIMM
Expansion slots 1 x PCIe® 3.0 x16(x8)

1 x PCIe® 3.0 x8(x8)

1 x PCIe® 3.0 x8(x4)

Onboard ports 4 x USB 3.0 ports

2 x USB 2.0 ports

1 x video port

1 x serial port

2 x Gigabit LAN port (RJ45)

1 x IPMI LAN port (RJ45)

SATA RAID2 Intel® C232 chipset with RSTe RAID support, SATA RAID 0, 1, 5, 10 default

2. Integrated SATA RAID on this model supports RAID 0, 1, 5, 10 on Windows OS only.

SAS RAID SAS RAID 0, 1, 5, 10 support via optional SAS RAID add-on-card
Network Controller Dual ports Gigabit Ethernet controller Intel® I210AT
Power Supply 650 W 80 PLUS® Gold-level fixed power supply
500 W 80 PLUS® Gold-level redundant power supply
System cooling Active CPU heat sink

Fixed system fan

Storage Up to 4 x 3.5″ SATA or up to 4 x 3.5″ SAS

Optional half-height SuperMulti optical drive

Drive Bays 4 x 3.5″ or 2.5″ hot-swap HDD

3 x 5.25″ bay

Dimensions 553 x 198 x 425 (mm), 20.9″ x 7.8″ x 16.7″
OS Support Microsoft® Windows Server® 2016

Microsoft® Windows Server® 2012 R2

Microsoft® Windows Server® 2012

Red Hat® Enterprise Linux® 7.1

Novell® SUSE® Linux® Enterprise Server 12

VMware ESXi 6.0 update 1

Server Management Software Acer Smart Server Manager
Security and service features Power/reset button lockout

Administrator/user password

Device boot control

Optional TPM 1.2/2.0

Power-on password

BIOS write-protected

Setup password

Warranty 3/3/3 Next Business Day
SRP RM 4488

C202i
5 Apr

C202i

Share your ideas wherever you go with Acer Portable LED Projectors.

Discuss concepts, show videos on big screens and motivate others while you’re on the road — without needing a computer. With models as slim as 1″ (24.5 mm), the world of self-expression now fits in your pocket.

Specifications


Native Resolution854 x 480
Maximum Resolution1600 x 1200
Standard Mode Brightness300 lm
Native Aspect Ratio16:9
Compatible Aspect Ratio4:3
Contrast Ratio5,000:1
Vertical Keystone Correction-20°/+20°
Maximum Vertical Sync60 Hz
Maximum Horizontal Sync33.20 kHz
Minimum Vertical Sync50 Hz
Colour Support16.7 Million Colours

Projection Lens

Throw Ratio1.3 (82″@2m)
Lens TypeManual Focus
Maximum Lens ApertureF/1.6
Maximum Focal Length5.02 mm
Minimum Diagonal Image Size73 cm (29″)
Maximum Diagonal Image Size254 cm (100″)
Minimum Projection Distance700 mm
Maximum Projection Distance2.90 m
Optical Zoom1 x

Lamp

Lamp TypeLED
Number of Lamps
1
Normal Mode Lamp Life20,000 Hours
Economy Mode Lamp Life30,000 Hours

Interfaces/ Ports

HDMIYes
Total Number of HDMI Ports1
Number of Audio Inputs1
Audio Line OutYes

Technical Information

Projection SystemDLP
Projection MethodFront
Video CompatibilityEDTV
HDTV
SDTV
Computer CompatibilityWindows PC
Wireless CapabilityEZCast APP supported
Miracast supported

Audio

Number of Speakers1
Speaker Output Power2 W
Speaker Output ModeMono

Power Description

Power Supply100 V AC~240V AC
Input Voltage120 V AC
230 V AC
Operating Power Consumption30 W
Operating Power Consumption
(Eco Mode)
6.50 W

Physical Characteristics

Temperature5°C to 40°C
Fan Noise29 dBA (Bright)
25 dBA (Eco)
Humidity80% Maximum Relative Humidity
Weight (Approximate)350 g

Miscellaneous

Package ContentsC202i DLP Projector
AC to DC Power Adapter
Protection Case
Quick Start Guide
Remote Control
Tripod

Warranty

Warranty2 Years (Upgradable)

SRP: RM899
