Description
Features
High Page Yield Ink Bottle
With high page yield ink bottle up to 8,300 pages, users can enjoy printing without having to worry about cost of ink, or ink supplies running low.
Optional Colour Printing
Allow users to perform colour document printing*.
*After the colour ink cartridge is depleted, it has to be replaced with new one or the contact protector has to be reinstalled.
Auto Document Feeder
Up to 35 sheets of originals can be loaded for batch scanning and copying.
Auto Duplex Printing
Enjoy heightened productivity and ease of use by printing on both sides of papers automatically.
2-Way Paper Feeding
Paper can be loaded for printing in 2 directions, via front cassette and rear feeding, eliminating the need to remove paper stacks and reloading.
Mobile and Cloud Printing
With the Canon PRINT Inkjet/SELPHY mobile app for iOS and Android OS, you can print documents stored in local device memory, or cloud storage.
Specifications
| Print Head / Ink | |
| Type | Permanent (Replaceable) |
| Number of Nozzles | Black: 640 nozzles (Optional Colour: 1152 nozzles) |
| Ink Cartridges | GI-70 (Pigment Black) Optional: CL-741, CL741XL |
| Maximum Printing Resolution | 600 (horizontal)*1 x 1200 (vertical) dpi |
| Print Speed*2
Based on ISO/IEC 24734 |
|
| Document (ESAT/Simplex) | Approx. 13.0 ipm (black) / 8.8 ipm (colour) |
| Photo (4 x 6″) (PP-201/Borderless) | – |
| Printable Width | Up to 203.2 mm (8″) |
| Printable Area | |
| Bordered Printing | #10 Envelope/DL Envelope: Top margin: 8 mm, Bottom margin: 12.7 mm, Left/Right 5.6 mmLTR/LGL: Top margin: 3 mm, Bottom margin: 5 mm, Left margin: 6.4mm, Right margin: 6.3 mmOthers: Top margin: 3 mm, Bottom margin: 5 mm, Left/Right margin: 3.4 mm |
| Bordered Auto 2-Sided Printing | Top/Bottom margin: 5 mm Left/Right margin: 3.4 mm (LTR: Left: 6.4 mm, Right: 6.3 mm) |
| Support Media | |
| Rear Tray | Plain Paper (64 – 105 g/m²) High Resolution Paper (HR-101N) Envelope |
| Cassette | Plain Paper (64 – 105 g/m²) |
| Paper Size | |
| Rear Tray | A4, A5, B5, LTR, LGL, Envelopes (DL, COM10), Card Size (91 x 55 mm)
[Custom size] * F4 is possible via custom size settings. |
| Cassette | A4, A5, B5, LTR
[Custom size] * F4 is possible via custom size settings. |
| Paper Handling (Maximum Number) | |
| Rear Tray | Plain Paper (A4, 64 g/m²) = 100 High Resolution Paper (HR-101N) = 80 |
| Cassette | Plain Paper (A4, 64 g/m²) = 250 |
| Support Media for Auto 2-sided printing | |
| Type | Plain Paper |
| Size | A4, A5, B5, LTR |
| Paper Weight | |
| Rear Tray | Plain Paper: 64 – 105 g/m² |
| Cassette | Plain Paper: 64 – 105 g/m² |
| Ink End Sensor | Electrode type and dot count type combined Optional Colour Cartridge; Dot count |
| Print Head Alignment | Auto/Manual |
Scan*3
| Scanner Type | Flatbed |
| Scanner Method | CIS (Contact Image Sensor) |
| Optical Resolution*4
Optical resolution scan is available, only when you use TWAIN Driver. |
1200 x 2400 dpi |
| Scanning Bit Depth (Input/Output) | |
| Grayscale | 16 bit/8 bit |
| Colour | RGB each 16 bit/8 bit |
| Line Scanning Speed*5 | |
| Grayscale | 1.5 ms/line (300 dpi) |
| Colour | 3.5 ms/line (300 dpi) |
| Maximum Document Size | |
| Flatbed | A4/LTR (216 x 297 mm) |
| ADF | A4/LTR/LGL |
Copy
| Maximum Document Size | A4/LTR |
| Compatible Media | |
| Size | A4/A5/B5/LTR/LGL/Card Size (91 x 55 mm) |
| Type | Plain Paper |
| Image Quality | 3 positions (Economy, Standard, High) |
| Density Adjustment | 9 positions, Auto intensity (AE copy) |
| Copy Speed*6
Based on ISO/IEC 24734 |
|
| Document (B&W) (sFCOT/Simplex) / (sESAT/Simplex) | Approx. 12 sec / approx. 10.7 ipm |
| Document (ADF): Black ESAT/Simplex | Approx. 11.5 ipm |
Network
| Protocol | SNMP, HTTP, TCP/IP (IPv4/IPv6) |
| Wired LAN | |
| Network Type | IEEE802.3u (100BASE-TX)
IEEE802.3 (10BASE-T) |
| Data Rate | 10M/100Mbps (Auto switchable) |
| Wireless LAN | |
| Network Type | IEEE802.11b/g/n |
| Frequency Band | 2.4 GHz |
| Channel*7 | 1 – 13 |
| Range | Indoor 50 m (depends on the transmission speed and conditions) |
| Security | WEP 64/128 bit WPA-PSK (TKIP/AES) WPA2-PSK (TKIP/AES) |
| Direct Connection (Wireless LAN) | Available |
Printing Solutions
| Canon Print Service (for Android) |
Available |
| PIXMA Cloud Link (from smartphone/tablet) |
Available |
| Canon PRINT Inkjet/SELPHY (for iOS/for Android) |
Available |
System Requirements*8
| Windows 10 / 8.1 / 7 SP1 (operation can only be guaranteed on a PC with a pre-installed Windows 7 or later)Mac: N/A |
General Specifications
| Operation Panel | |
| Display | 2-Line LCD |
| Language | 32 Selectable Languages: Japanese / English / German / French / Italian / Spanish / Dutch / Portuguese / Norwegian / Swedish / Danish / Finnish / Russian / Czech / Hungarian / Polish / Slovene / Turkish / Greek / Simplified Chinese / Traditional Chinese / Korean / Indonesian / Slovakian / Estonian / Latvian / Lithuanian / Ukrainian / Romanian / Bulgarian / Thai / Croatian / Vietnamese |
| ADF | |
| Paper Handling (Plain Paper) | A4, LTR = 35, LGL = 5, others = 1 |
| Interface | USB 2.0 |
| Operating Environment*9 | |
| Temperature | 5 – 35°C |
| Humidity | 10 – 90% RH (no dew condensation) |
| Recommended Environment*10 | |
| Temperature | 15 – 30°C |
| Humidity | 10 – 80% RH (no dew condensation) |
| Storage Environment | |
| Temperature | 0 – 40°C |
| Humidity | 5 – 95% RH (no dew condensation) |
| Quiet Mode | Available |
| Acoustic Noise (PC Print) | |
| Plain Paper (A4, B/W)*11 | Approx. 50.5 dB(A) |
| Power | AC 100-240 V, 50/60 Hz |
| Power Consumption | |
| OFF | Approx. 0.3 W |
| Standby (scanning lamp is off) USB connection to PC |
Approx. 0.8 W |
| Standby (all ports connected, scanning lamp is off) [EU only – for ErP Lot 26 regulation] |
Approx. 1.7 W |
| Time to enter Standby mode [EU only – for ErP Lot 26 regulation] | Approx. 11 min 9 sec |
| Printing*12 USB connection to PC |
Approx. 10 W |
| Duty Cycle | Up to 15,000 pages/month |
| Dimension (WxDxH) | |
| Factory Configuration | Approx. 403 x 369 x 234 mm |
| Output/ADF trays extended | Approx. 403 x 701 x 305 mm |
| Weight | Approx. 9.2 kg |
Page Yield
| Plain Paper (A4 pages) (ISO/IEC 24712 test file)*13 |
Standard: GI-70 PGBK*14: 6,000Economy*15: GI-70 PGBK: 8,300Optional: CL-741: 180 CL-741XL: 400 |
